Steel Structure House C Channel Roll Forming Machine

    Payment Type: L/C,T/T,Money Gram,Western Union
    Incoterm: FOB,CFR,CIF
    Min. Order: 1 Set/Sets
    Delivery Time: 30 Days
Basic Info

Model No.: KYT

Tile Type: Colored Steel

Certification: CE, ISO

Condition: New

Customized: Customized

Usage: Roof

Transmission Method: Hydraulic Pressure

Place Of Origin: China

After-sales Service Provided: Engineers Available To Debug The Machine Overseas

Brand: KYT

Warranty: 24 Months

RAW MATERIAL: Colored Steel Sheet,galvanized Steel Sheet

Thickness Of Raw Material: 1.5-3mm

Control System: PLC

Cutting Type: Hydraulic

Voltage: As Your Required

Production Capacity: 10-15meter/min

Additional Info

Packaging: Seaworthy packing

Productivity: 30 sets per month

Brand: KAIYITE

Transportation: Ocean

Place of Origin: China

Supply Ability: 30 sets per month

Certificate: ISO9000

HS Code: 84552210

Port: Tianjin,Shanghai

Product Description

Steel Structure House C Purlin Roll Forming Machine

The raw material of the steel structure house c Purlin Roll Forming Machine is 1 mm to 3 mm . We design this machine for our India client . It adopts the hydraulic cutting system . Also it has punching system . Normally the c purlin roll forming machine has hole . When we feed the raw material of the steel structure house c purlin roll forming machine , the coil enter into the feeding table , It is used to control the width and position of the steel sheet. The sheet is guided into the machine with correct position, to make sure the panel is neat and parallel.

The working follow of the steel purlin roll forming machine

Decoiling the sheet→Sheet guiding→Roll forming→Measure length→Cutting the panel→Panels to product stand

process-flow



roll forming machine for c purlin

C Z PURLIN SIZE

Technical parameters:

Material thickness: 1.5 - 3 mm

Size of purlin : 80-300mm

Power:

Voltage : 380V/3PH/50HZ

Main Motor : 7.5 KW

Hydraulic Motor : 5.5 KW

Hydraulic Pressure : 10-12MPa

Main machine

Flattening rollers : 7 rollers

Main forming station : 13 steps

Forming Shaft : diameter 85 mm, 45# steel thermal refining

Roller Material : GCR15 bearing steel quenching HRC58-60°

Main machine body : 350# H steel welded

Transmission : Chain and Sprocket, chain size 2 inch

Wall plate : 20 mm thickness

Blade material : Cr12 mould steel with quenched treatment60-62°

Punch Mould (if needed) : Cr12 quenched

Forming Speed : 7-10m/min for standard solution

Hydraulic cutting system : fully automatic . Material of blades: Cr12, quenching treatment.

Roll Former For C Section

Forming rollers

Specification: 45# steel, CNC Lathes, heat treated 45# steel, roller surfaces polishing, hard plating. The polished surface and the heat treatment towards the molds also can keep the molding. Plate surface smooth and not easy to be marked when it is being stamped . Feature: hard chrome plating, 0.05 mm

Colored Used C Z Purlin Roll Forming

Main frame

specification: 350 H steel. feature: More stable, no shaking

C Purlin Bracket Roll Forming Machine Roll Forming Machine

Guide device

It is used to control the width and position of the steel sheet.The sheet is guided into the machine with correct position, to make sure the panel is neat and parallel.

C Channel Machinery

c purlin application

C Z purlin produced by the Purlin Roll Forming Machine is good in bending resistance, straightness, and it can cut, punch automatically, it is very easy and convenient to use. It can be used as bearing structure in big and medium sized building, such as factories, warehouses, garages, hangars, gyms, exhibitions, theater and so on.

application of c purlin roll forming machine

Manual uncoiler

It is used to support the steel coil and realize the uncoiling by means of rotatory movement. The steel coil is uncoiled manually. The capacity of this uncoiler

is 5 ton, and it is capable for most of the coils.

Decoiler

Feeding

Receiving the raw material (steel sheet), it guarantees the products are neat, parallel and everything is uniformity.

C Channel Machinery

Electrical control cabinet

PLC is adopted to organize all action of the machine. The length of workpiece is adjustable according to the setting of on the PLC. Two optional control modes:Automatic and manual. By automatic mode, the machine can realize fully automatic working .

Plc Control Box

Hydraulic system

Hydraulic oil:40#.Hydraulic oil into the hydraulic oil tank, the pump drives the cutter machine to begin the cutting job.

Hydraulic Pump

Client came to visit our factory for the Interchangeable C Z Purlin Roll Forming Machine , rollers Shutter Door Roll Forming Machine , Door Frame Roll Forming Machine and other Roof And Wall Panel Roll Forming Machine .

Client 1
